Description
CPU
Intel® Quad-core 2.4GHz
Memory
2GB DDR3 RAM
High Performance
Up to 449MB/s reading, 396MB/s writing performance
Scalability
Expandable up to 24 drives
Features
Real-time collaboration on your private cloud
Office is a collaboration package combining the convenience and usability of public clouds with the data privacy and security guaranteed by private clouds. It allows you to work seamlessly together on documents and spreadsheets in a protected environment.
Flexible storage scalability
As your data storage needs grow, DS2415+ can be connected with a DX1215 expansion unit for additional storage on the fly, allowing up to 24 drives to be installed with minimal effort.
Ultimate file management and sharing
File Station is a web-based, fast and secure management tool built to allow easy, drag-and-drop operation without requiring any complex setup on Mac or PC. Advanced search and filtering tools allow for easy organization and sharing of files with just a link. Supports SMB, FTP, AFP, NFS, WebDAV, compatible with any environment.
Btrfs: Next generation storage efficiency
Btrfs file system introduces the most advanced storage technologies to meet the management needs of modern large scale businesses:
Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
File or folder level data restoration makes data recovery fast and flexible
Automatic file self-healing detects and recovers corrupted files without user intervention
Hardware Specifications
| Hardware Specifications | |
| CPU | |
| CPU Model | Intel Atom C2538 |
| CPU Architecture | 64-bit |
| CPU Frequency | Quad Core 2.4 GHz |
| Hardware Encryption Engine (AES-NI) | |
| Memory | |
| System Memory | 2 GB DDR3 |
| Memory Module Pre-installed | 2GB (1 x 2GB) |
| Total Memory Slots | 2 |
| Memory Expandable up to | 6 GB (2 GB + 4 GB) |
| Storage | |
| Drive Bays | 12 |
| Maximum Drive Bays with Expansion Unit | 24 |
| Compatible Drive Type*(See all supported drives) |
|
| Maximum Internal Raw Capacity | 120 TB (10 TB drive x 12) (Capacity may vary by RAID types) |
| Maximum Raw Capacity with Expansion Units | 240 TB (10 TB drive x 24) (Capacity may vary by RAID types) |
| Maximum Single Volume Size | 108 TB |
| Hot Swappable Drive | |
| External Ports | |
| RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| USB 3.0 Port | 4 |
| Expansion Port | 1 |
| File System | |
| Internal Drives |
|
| External Drives |
|
| Notes | exFAT Access is purchased separately in Package Center. |
| Appearance | |
| Size (Height x Width x Depth) | 270 mm x 300 mm x 340 mm |
| Weight | 9.24 kg |
| Others | |
| System Fan | 120 mm x 120 mm x 2 pcs |
| Fan Speed Mode |
|
| Easy Replacement System Fan | |
| Wireless Support (dongle) | |
| Power Recovery | |
| Noise Level* | 27.1 dB(A) |
| Scheduled Power On/Off | |
| Wake on LAN/WAN | |
| Power Supply Unit / Adapter | 500W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 73.44 W (Access) 37.13 W (HDD Hibernation) |
| British Thermal Unit | 250.59 BTU/hr (Access) 126.70 BTU/hr (HDD Hibernation) |
| Environment Temperature | |
| Operating Temperature | 5°C to 35°C (40°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification |
|
| Warranty | 3 Years |
| Notes |
|
| DSM Specifications ( See more ) | |
| Storage Management | |
| Maximum Internal Volume Number | 512 |
| Maximum iSCSI Target Number | 32 |
| Maximum iSCSI LUN | 256 |
| iSCSI LUN Clone/Snapshot, Windows ODX | |
| Supported RAID Type |
|
| RAID Migration |
|
| Volume Expansion with Larger HDDs |
|
| Volume Expansion by Adding a HDD |
|
| Global Hot Spare Supported RAID Type |
|
| SSD Support | |
| SSD Read/Write Cache(White Paper) | |
| SSD TRIM | |
| File Sharing Capacity | |
| Maximum Local User Accounts | 2048 |
| Maximum Local Groups | 256 |
| Maximum Shared Folder | 512 |
| Maximum Shared Folder Sync Tasks | 8 |
| Maximum Concurrent CIFS/AFP/FTP Connections | 512 |
| Windows Access Control List (ACL) Integration | |
| NFS Kerberos Authentication | |
| High Availability Manager | |
| Log Center | |
| Syslog Events per Second | 800 |
| Virtualization | |
| VMware vSphere 5 with VAAI | |
| VMware vSphere 6 with VAAI | |
| Windows Server 2012 | |
| Windows Server 2012 R2 | |
| Citrix Ready | |
| OpenStack | |
| Add-on Packages (learn more about the complete add-on package list) | |
| Antivirus by McAfee (Trial) | |
| Central Management System | |
| Chat | |
| Maximum Users | 400 |
| Notes |
|
| Cloud Station Server | |
| Maximum Concurrent File Transfers | 512 |
| Maximum Concurrent File Transfers (with RAM expansion) | 1500 |
| DDSM | |
| Maximum DDSM Number (Licenses required) | 10 (including 1 Free License) (Learn more) |
| Document Viewer | |
| Download Station | |
| Maximum Concurrent Download Tasks | 80 |
| exFAT Access (optional) | |
| MailPlus / MailPlus Server | |
| Free Email Accounts | 5 (Licenses required for additional accounts) |
| Recommended MailPlus Client Number | Up to 90 (Btrfs) / 100 (EXT4) |
| Maximum Server Performance | 825,000 (Btrfs) / 884,000 (EXT4) emails per day, approx. 25.2 GB (Btrfs) / 27 GB (EXT4) |
| Notes |
|
| Media Server | |
| DLNA Certification | |
| Office | |
| Maximum Users | 400 |
| Maximum Simultaneous Editing Users | 80 |
| Notes |
|
| Snapshot Replication | |
| Maximum Snapshots per Shared Folder | 1024 |
| Maximum Snapshots of all Shared Folder | 65536 |
| Surveillance Station | |
| Maximum IP cam (Licenses required) | 40 (including 2 Free License) (See All Supported IP Cameras) |
| Total FPS (H.264)* | 1200 FPS @ 720p (1280×720) 900 FPS @ 1080p (1920×1080) 320 FPS @ 3M (2048×1536) 270 FPS @ 5M (2591×1944) |
| Total FPS (MJPEG)* | 540 FPS @ 720p (1280×720) 200 FPS @ 1080p (1920×1080) 150 FPS @ 3M (2048×1536) 90 FPS @ 5M (2591×1944) |
| Notes | Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera. |
| Video Station | |
| Video Transcoding | Group 1 – Type 1 (See more) |
| Maximum Transcoding Channel Number | 1 channel, 30 FPS @ 1080p(1920×1080), H.264 (AVC)/MPEG-4 Part 2 (XVID, DIVX5)/MPEG-2/VC-1 |
| VPN Server | |
| Maximum Connections | 20 |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content |
|
| Optional Accessories |
|
| Hardware Specifications | |
| CPU | |
| CPU Model | Marvell Armada 370 88F6707 |
| CPU Architecture | 32-bit |
| CPU Frequency | 800 MHz |
| Hardware Encryption Engine | |
| Memory | |
| System Memory | 256 MB DDR3 |
| Storage | |
| Drive Bays | 2 |
| Compatible Drive Type*(See all supported drives) |
|
| Maximum Internal Raw Capacity | 20 TB (10 TB drive x 2) (Capacity may vary by RAID types) |
| Maximum Single Volume Size | 16 TB |
| Notes |
|
| External Ports | |
| RJ-45 1GbE LAN Port | 1 |
| USB 2.0 Port | 2 |
| File System | |
| Internal Drives | EXT4 |
| External Drives |
|
| Notes |
|
| Appearance | |
| Size (Height x Width x Depth) | 165 mm x 100 mm x 225.5 mm |
| Weight | 0.87 kg |
| Others | |
| System Fan | 92 mm x 92 mm x 1 pcs |
| Fan Speed Mode |
|
| Wireless Support (dongle) | |
| Power Recovery | |
| Noise Level* | 18.4 dB(A) |
| Scheduled Power On/Off | |
| Power Supply Unit / Adapter | 60W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 13.73 W (Access) 5.12 W (HDD Hibernation) |
| British Thermal Unit | 46.88 BTU/hr (Access) 17.48 BTU/hr (HDD Hibernation) |
| Environment Temperature | |
| Operating Temperature | 5°C to 40°C (40°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification |
|
| Warranty | 2 Years |
| Notes |
|
| DSM Specifications ( See more ) | |
| Storage Management | |
| Maximum Internal Volume Number | 256 |
| Supported RAID Type |
|
| RAID Migration | Basic to RAID 1 |
| Volume Expansion with Larger HDDs |
|
| Volume Expansion by Adding a HDD | Synology Hybrid RAID |
| File Sharing Capacity | |
| Maximum Local User Accounts | 512 |
| Maximum Local Groups | 128 |
| Maximum Shared Folder | 256 |
| Maximum Shared Folder Sync Tasks | 2 |
| Maximum Concurrent CIFS/AFP/FTP Connections | 64 |
| Windows Access Control List (ACL) Integration | |
| NFS Kerberos Authentication | |
| Log Center | |
| Syslog Events per Second | 50 |
| Add-on Packages (learn more about the complete add-on package list) | |
| Cloud Station Server | |
| Maximum Concurrent File Transfers | 64 |
| Download Station | |
| Maximum Concurrent Download Tasks | 20 |
| exFAT Access (optional) | |
| Media Server | |
| DLNA Certification | |
| Office | |
| Maximum Users | 3 |
| Maximum Simultaneous Editing Users | 3 |
| Notes |
|
| Surveillance Station | |
| Maximum IP cam (Licenses required) | 5 (including 2 Free License) (See All Supported IP Cameras) |
| Total FPS (H.264)* | 50 FPS @ 720p (1280×720) 20 FPS @ 1080p (1920×1080) 10 FPS @ 3M (2048×1536) 10 FPS @ 5M (2591×1944) |
| Total FPS (MJPEG)* | 20 FPS @ 720p (1280×720) 10 FPS @ 1080p (1920×1080) 10 FPS @ 3M (2048×1536) 6 FPS @ 5M (2591×1944) |
| Notes | Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera. |
| Video Station | |
| Video Transcoding | Group 2 (See more) |
| VPN Server | |
| Maximum Connections | 5 |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content |
|
| Optional Accessories |
|
